Ultracur3D® RG 3280
Description
Description
Ceramic-Filled Resin with Exceptionally High Stiffness and Temperature Resistance
Ultracur3D® RG 3280 is the first composite material we are adding to our rigid product line. Due to the high loading of ceramic particles, this material has an extremely high stiffness around 10 GPa and an HDT B above 280°C.
These outstanding properties place Ultracur3D® RG 3280 in an exceptional position among our other resins. Moreover, despite the high particle loading, the viscosity is kept low, and the settling of particles is limited, making this resin very easy to handle and print. Its high stiffness and temperature resistance make this the perfect material for tooling, molding, and wind tunnel testing.
The material has a white, ceramic-like color and feel.
Benefits at a Glance:
- Superior stiffness
- Superior temperature performance
- Very fast and easy to print
- High suspension stability
Example Applications:
- Tooling
- Molding
- Wind tunnel testing
Material Properties:
- Young’s modulus: 10,000 MPa
- Tensile strength: 76 MPa
- Heat deflection temperature: >280 °C
- Viscosity, 30 °C: 230 mPas
Use Case of Ultracur3D® RG 3280
Additive Manufacturing Delivers Durable Mold Parts for Quick Tool Production
Innovative material and enhanced design provides superior performance and exceptional durability for industrial filtration screens
